MxD SeaCam

Broadcast-grade 4K imaging system for deep-sea exploration

Request a quote

Description

Built around a Sony HDC-50 broadcast camera head with a 2/3" 3-CMOS global-shutter block, the MxD delivers 4K UHD with HDR and the BT.2020 color space. A Canon 15x wide zoom behind a custom four-element dome corrector spans 96° to 8.4° HFOV with near-zero distortion. The titanium housing is rated to 4,000 m (7,000 m option), and video and telemetry share a single fiber to a topside hub with 12G-SDI output.

Highlights

  • 4K UHD with HDR and BT.2020 color
  • 3-CMOS 2/3" global-shutter sensors
  • 15x optical zoom, optional 2x extender
  • 96° HFOV with custom corrector optics
  • Single-fiber link to a topside 12G-SDI hub
  • Titanium housing rated to 4,000 m (7,000 m option)

Gallery

DeepSea Power & Light MxD SeaCam — 2 DeepSea Power & Light MxD SeaCam — 3
